■ 제품사양 [Specifications]
| 기종명 Model |
호칭마력 Nominal HP HP (kW) |
전원 Power Supply Volt x Ph x Hz |
냉각능력(kcal/hr) Temperature Difference CT50℃/ET℃ |
압축기 Compressor |
증발기 Evaporator |
응축기 Condenser |
||||
|---|---|---|---|---|---|---|---|---|---|---|
| +5℃ | 0℃ | -5℃ | 형식 Type |
모델 Model |
냉동기유 봉입량 Oir Volume |
냉수량 Water flow(ℓ/min) |
적용 모델 Application Model |
|||
| BSCH-A030SBP | 3 (2.2) | 220 x 1 x 60 | 8130 | 6820 | 5570 | Scroll | ZB21KQ | 1ℓ | 20.5 | RCAV-3HP |
| 220/380 x 3 x 60 | ||||||||||
| BSCH-A050SBP | 5 (3.75) | 220 x 1 x 60 | 14100 | 11840 | 9810 | Scroll | ZB38KQ | 2ℓ | 32.0 | RCAV-5HP |
| 220/380 x 3 x 60 | ||||||||||
| BSCH-A075SBP | 7.5 (5.5) | 220/380 x 3 x 60 | 18600 | 15500 | 12830 | Scroll | ZB48KQ | 2ℓ | 64.1 | RCAV-7.5HP |
| BSCH-A100SBP | 10 (7.5) | 220/380 x 3 x 60 | 29250 | 24700 | 20500 | Scroll | ZB76KQ | 3ℓ | 76.9 | RCAV-10HP |
| BSCH-A150SBP | 15 (11.25) | 220/380 x 3 x 60 | 35600 | 29600 | 24100 | Scroll | ZB95KQ | 3ℓ | 124.7 | RCAV-15HP |
| BSCH-A200SBP | 20 (15) | 220/380 x 3 x 60 | 42500 | 35500 | 29100 | Scroll | ZB114KQ | 3ℓ | 152.9 | RCAV-20HP |
| BSCH-A250SBP | 25 (18.75) | 220/380 x 3 x 60 | 60750 | 50750 | 42000 | Scroll | ZR250KC | 4ℓ | 169.0 | RCAV-25HP |
| BSCH-A300SBP | 30 (22.5) | 220/380 x 3 x 60 | 74750 | 62000 | 50750 | Scroll | ZR310KC | 7ℓ | 196.1 | RCAV-30HP |
| BSCH-A400SBP | 40 (30.0) | 220/380 x 3 x 60 | 92500 | 77500 | 64000 | Scroll | ZR380KC | 7ℓ | 284.8 | RCAW-40HP / RCAV-40HP |
| BSCH-A5002SBP | 50 (37.5) | 220/380 x 3 x 60 | 117500 | 98000 | 80750 | Scroll | ZR250KC x 2EA | 9ℓ | 361.7 | RCAW-50HP / RCAV-50HP |
| BSCH-A6002SBP | 60 (45) | 220/380 x 3 x 60 | 149500 | 124000 | 101500 | Scroll | ZR310KC x 2EA | 11ℓ | 406.9 | RCAW-60HP |
| BSCH-A8002SBP | 80 (60) | 220/380 x 3 x 60 | 182250 | 152250 | 125750 | Scroll | ZR380KC x 2EA | 13ℓ | 548.2 | RCAV-80HP |
■ 제품치수 [Dimensions]
| 기종명 Model |
Pump Model (kW) | L (mm) |
W (mm) |
H (mm) |
A (mm) |
B (mm) |
C (A) |
D (A) |
F (A) |
|---|---|---|---|---|---|---|---|---|---|
| BSCH-A030SBP | CM1-2 (0.43) | 1178 | 678 | 830 | 580 | 528 | 1/2″ | 3/8″ | 25 |
| BSCH-A050SBP | CM3-2 (0.43) | 1178 | 678 | 830 | 580 | 528 | 1/2″ | 1/2″ | 25 |
| BSCH-A075SBP | CM3-3 (0.74) | 1465 | 750 | 899 | 846 | 614 | 3/4″ | 5/8″ | 25 |
| BSCH-A100SBP | CM5-2 (0.74) | 1600 | 873 | 937 | 1030 | 704 | 7/8″ | 5/8″ | 32 |
| BSCH-A150SBP | CM5-4 (1.7) | 1600 | 873 | 937 | 1030 | 704 | 7/8″ | 5/8″ | 32 |
| BSCH-A200SBP | CM10-1 (1.28) | 1895 | 910 | 937 | 1234 | 704 | 7/8″ | 7/8″ | 40 |
| BSCH-A250SBP | - | 2105 | 1050 | 1150 | 1346 | 1002 | 1-3/8″ | 7/8″ | 65 |
| BSCH-A300SBP | - | 2200 | 1100 | 1195 | 2150 | 1000 | 1-3/8″ | 7/8″ | 65 |
| BSCH-A400SBP | - | 2600 | 1100 | 1300 | 2500 | 1000 | 1-3/8″ | 7/8″ | 80 |
| BSCH-A500SBP | - | 2600 | 1000 | 1300 | 2500 | 1000 | 1-5/8″ | 1-1/8″ | 100 |
| BSCH-A600SBP | - | 2700 | 1100 | 1300 | 2650 | 1050 | 1-5/8″ | 1-1/8″ | 100 |
| BSCH-A800SBP | - | 2700 | 1100 | 1300 | 2550 | 1050 | 1-5/8″ | 1-1/8″ | 125 |
